Classical / Wrapped V Belts

Classical V-belts remain the most widely used power transmission belts. They are proven to offer dependable service with minimum maintenance in a variety of medium and heavy duty industrial drives. Classic v-belts are just that, classic in design and application.

The classic v-belt is the most tried and true style of v-belt in the market. Originally designed to replace leather belts in a variety of industries including agriculture, textile industry automotive, facility maintenance etc. Also known as light duty v-belts, they are designed with a 40° angle to "wedge" the belt into the groove of the pulley. The greater the load, the greater the wedging action. The manufacturing process combines a rubber compound with a polyester cord to increase strength and stability.

Features

• Special CR treated outer jacketing fabric for higher durability
• Anti-static, oil & heat resistant
• Maximum Belt linear speed (Classical section: up to 30 m/sec, Wedge section: up to 42 m/sec, Narrow section: up to 45 m/sec)
• Temperature range: -30°C to +80°C
