Banded Cogged Belts

Application

Banded Belts combines the longer life and superior performance of the Cog-Belt with the stability of banded construction & Banded belts are also ideal for heavy industrial power transmission applications with vertical running shafts and large center distances. It can withstand impact loads, Oil and heat resistant, static dissipating etc are some of its exclusive features.

Molded cogged construction, cushion compound cord layer, and fiber core give it superior performance and durability characteristics.

Constructional Details

• Specially designed top band for extra protection against reverse bend & foreign particles
• High modulus cushion compound for superior adhesion
• High tenacity, low stretch specially treated polyester cord
• Fibre loaded, thermal resistant, high modulus base compound
• Moulded cog offers better flexibility and accelerates heat dissipation rate

Features

• Extended power transmission capacity up to 25% as compared to standard single Belts
• Lesser number of Belts is required as compared to a multiple single-Belt drives
• Unique cog profile enhances the flexibility and heat dissipation rate
• Extended service life
• Anti-static, oil and heat resistant
• Temperature range: -25ºC to +100ºC
